Wedge Anchor

Wedge Anchor

Sleeve anchors (wedge anchors) have low requirements on the depth and cleanliness of holes in concrete. They are easy to install and cost-effective. Select the proper embedment depth according to the thickness of the fixture plate. Tensile capacity rises with increased embedment depth. This product delivers reliable expansion performance. Body materials include stainless steel, carbon steel and other metallic materials.

Specification Parameters

1. Size Range: M8-M20

2. Material: Carbon Steel / Stainless Steel

3. Surface Treatment: Electro-galvanized / Hot-dip Galvanized

4. Packaging: Box packed then cartoned

Product Features

1. Equipped with long threads for easier installation, commonly used for heavy-load facilities.

2. To achieve reliable and high fastening force, the expansion sleeve on the anchor must expand fully. The expansion sleeve shall not detach from the rod or twist and deform inside the hole.

3. The stated tensile values are tested under concrete strength of 260~300 kgf/cm². The maximum safe working load shall not exceed 25% of the rated value.

Application Fields

Suitable for concrete and dense natural stone, metal structures, metal profiles, base plates, support plates, brackets, railings, windows, curtain walls, machinery, girders, joists, supports and so on.
